LimeNET Mini avec mini pc et limesdr

Beschreibung

Carte mère:

• • Taille: 105 x 110 mm
  • Processeur: Intel Core i7-7500U, two cores, 2.7 GHz (3.5 GHz boost)
  • Memoire: 32 GB (2 x 16 GB SO-DIMM) DDR4 2133 MHz
  • Stockage: 512 GB SSD
  • Video
    • Intel HD Graphics 620
  • Mini DisplayPort 1.2: 3840 x 2160 @ 60 Hz
  • HDMI 2.0: 4096 x 2160 @ 60 Hz
  • Audio: Realtek ALC255
  • Connectivité
    • 1 x USB 3.1 Type-C
    • 1 x USB 3.1
    • 2 x USB 3.0
    • 1 x Gigabit Ethernet
  • Wi-Fi + Bluetooth (tentatively Intel Dual Band Wireless-AC 3168)

Alimentation

• Alimentation: 19 VDC input @ 3.42 A, 65 W
• Ventilateur: simple

Boitier

• Matière: injection molded plastic and stainless steel
• Dimensions: 11.2 x 12.0 x 5.2 cm (exclusive of antennas)
• Partitions: top (black) holds mini PC, bottom (green) holds LimeSDR

Radio (Integrée)

• Board: LimeSDR USB micro Type-B
• Shielding: attached to LimeSDR
• Antennas: five (of which one is dedicated for HF reception)
• Cables: 5 x U.FL (internal and pre-installed)
• Transmit Range: Approximately 15 meters for LTE
• Power Amplifier: None
• Filters: None
